Description
This JW-LB-01(L) Solar Powered Aviation Obstruction Light is low intensity. It uses a reliable eco-lighting solution and designed specifically for aviation and obstruction purposes. Whether it’s high-rise buildings, power towers, construction cranes, airports, highway express lanes, radio and television towers, microwave towers, tall chimneys, bridge pylons, exploration well sites, ship navigation, heliport, or aircraft runways, this light is perfect for marking potential obstacles.
With its explosion-proof design, this solar aviation obstruction light offers enhanced safety and durability. It can withstand harsh environmental conditions, ensuring long-lasting performance even in challenging weather conditions. Its robust construction guarantees resistance against impacts, vibrations, and extreme temperatures, making it suitable for a wide range of applications.
Easy installation and low maintenance further add to the appeal of this product. It comes with pre-drilled holes and mounting brackets for effortless installation on various surfaces. Additionally, its self-contained design eliminates the need for frequent bulb replacements or complex wiring arrangements, reducing operational costs and minimizing downtime.
Specification:
|
Mode: |
JW-LB-01(L) |
|
Light source life: |
>100000hours |
|
Light source: |
LED |
|
Power supply: |
Mono crystalline silicon solar panel |
|
Battery capacity: |
12.8V14AH |
|
Battery type： |
Lithium iron phosphate battery |
|
Battery life： |
>5 years |
|
Solar panel power： |
10w |
|
Solar panel voltage： |
16.5V |
|
Solar panel life： |
>20years |
|
Power consumption: |
≤2.6W |
|
Vertical divergence： |
>10° |
|
Horizontal out-put： |
360° |
|
Visual range： |
5km |
|
FAA classify： |
L810 |
|
Overall size(mm)： |
300mm×292mm×320mm |
|
Power supply： |
Solar panel |
|
Weight： |
Around 3.2Kg |
|
Emitting color： |
Red |
|
Ambient temperature: |
-40℃~55℃ |
| Surge protection grade： |
3KA |
|
Wind load: |
80m/s |
|
Working mode： |
Steady burning |
|
Steady light intensity： |
32.5cd |
|
Protection Standard： |
IP65 |
|
Continuous working time： |
>7days(10hours a day) |
|
Optically Controlled Ambient Brightness： |
50/100LUX |
Features
- Housing adopt high intensity casting aviation aluminum.
- Built-in dual light source design,when main light default, it can switch to standby light to work automatically.
- Adopt with independent research and development advanced optical lighting system,Spotlight angle meets CAAC and ICAO requirements.
- With surge protection device, which can adopt to extremely bad working environment.
- Adopt high conversion efficiency monocrystalline silicon chip, its service life is more than 20 years.
- With the impact resistance, anti lightning, resistant to sunlight, anti snow, can resist typhoons, hail and other severe weather.
- Built-in independent battery charge and discharge management module, easy maintenance.
- Adopt high safety and long lifespan of lithium iron phosphate battery, whose lifespan is more than 3 times that of ordinary lead-acid battery.
- Remote control and telemetry can be customized.
- Integrated high-power solar panel design, high charging efficiency.
Usage/Application:
- If the storage time of the product is over 3 months, to prevent battery damage,it is recommended to place the product in outdoor under sunshine for 3 days every 3 months.
- Installation personnel must check whether the power switch of the device is turned on and the fixing screws are tightened after finish operating.
- Non-professional personnel should not repair the equipment to avoid enlarging the fault and personal injury.
- For solar product storage note, please do strictly comply with the provisions.
